Stereo microscope RED-220 binocular lens tube, 30° viewing angle, WF10X/20mm with 4X, 10X, 40X and 100X objective lens

Stereo microscope RED-220 binocular lens tube, 30° viewing angle, WF10X/20mm with 4X, 10X, 40X and 100X objective lens
Manufacturer: Motic
SKU: 6.285 859
Delivery date: 14 Business Days
€555.14 incl tax
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Designed for advanced biology students, teachers, doctors and lab technicians.
  • Binocular head Siedentopf type, 30° inclined, 360° rotating
  • Widefield eyepieces WF10X/20 mm
  • Reversed quadruple revolving nosepiece
  • Achromatic Semi-Plan objectives SP 4X, 10X, 40X S, 100X S Oil
  • Coaxial coarse and fine focusing system with tension adjustment
  • Built-in low position coaxial mechanical stage
  • Focusable Abbe condenser N.A. 1.25 with iris diaphragm
  • LED illumination 3 W with intensity control
  • Power supply 100-240 V (CE)
  • Dust cover, immersion oil (5 ml) and cord hanger
  • Monocular-/Trinocular equipment available
Products specifications
Attribute nameAttribute value
CondenserAbbe N.A. 1.25
Depth260 mm
Depth stage135 mm
Dimensions (WxDxH)175 x 260 x 354 mm
Height354 mm
Inclination <br>angle tube30°
Interpupillary <br>distance55 ... 75 mm
Light typeLED
Magnification <br>eyepiecesWF 10x/20 mm
Magnification <br>objectives4x, 10x, 40x, 100x
Max. interpupillary <br>distance75 mm
Max. voltage240 V
Min. interpupillary <br>distance55 mm
Min. voltage100 V
Power supply100 ... 240 V
Revolving nosepiece4-fold
Stage (WxD)140 x 135 mm
TubeBinocular
TypeRED 220
Type of <br>auxiliary energyMains connection
Type of illuminationTransmitted light
Weight5.7 kg
Width175 mm
Width stage140 mm
